D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 76
Section 5 - Connect to the Internet
IPv6 WAN Settings
Path: Network > IPv6 > IPv6 WAN1 Settings
For IPv6 WAN connections, this router can have a static IPv6 address or receive connection information when
congured as a DHCPv6 client. In the case where the ISP assigns you a xed address to access the internet, the
static conguration settings must be completed. In addition to the IPv6 address assigned to your router, the
IPv6 prex length dened by the ISP is needed. The default IPv6 Gateway address is the server at the ISP that
this router will connect to for accessing the internet. The primary and secondary DNS servers on the ISP’s IPv6
network are used for resolving internet addresses, and these are provided along with the static IP address and
prex length from the ISP.
When the ISP allows you to obtain the WAN IP settings via DHCP, you need to provide details for the DHCPv6
client conguration. The DHCPv6 client on the gateway can be either stateless or stateful. If a stateful client is
selected the gateway will connect to the ISP’s DHCPv6 server for a leased address. For stateless DHCP there need
not be a DHCPv6 server available at the ISP, rather ICMPv6 discover messages will originate from this gateway
and will be used for auto conguration.
A third option to specify the IP address and prex length of a preferred DHCPv6 server is available as well.
To congure a dynamic (DHCP) IPv6 Internet connection:
1. Click Network > IPv6 > IPv6 WAN1 Settings.
2. Complete the elds in the table below and click Save.
Field Description
Connection Type Select DHCPv6 from the drop-down menu.
DHCPv6 Auto Conguration Select either Stateless Address or Stateful Address.
Prex Delegation
Select this option to request router advertisement prex from any available
DHCPv6 servers available on the ISP, the obtained prex is updated to the advertised prexes on
the LAN side. This option can be selected only in Stateless Address Auto Conguration mode of
DHCPv6 Client.
Save Click Save to save your settings.
Dynamic IP

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
