D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 176
Section 8 - Security
Path: Security > Web Content Filter > Static Filtering > Approved URL
The approved URL list is an acceptance list for all URL domain names. Domains added to this list are allowed
in any form. For example, if the domain “dlink” is added to this list then all of the following URL’s are permitted
access from the LAN: www.dlink.com, support.dlink.com, etc.
Importing/exporting from a text or CSV le is also supported.
To add/import/export URLs to the approved list:
1. Click Security > Web Content Filter > Static Filtering > Approved URL tab.
Approved URL
2. To import a list from a text/CSV le, click Upload URLs List from File. If you want to export the current
list, click Export URLs List to File. To add a new URL, click Add New Approved URL.
3. Enter a URL and click Save.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
