D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 201
Section 8 - Security
Intel® AMT
Path: Security > Firewall > Intel® AMT
Intel® Active Management Technology (AMT) allows you to remotely access and manage every networked
device, even those that lack a working operating system or hard drive, or are turned o as long as the computer
is connected to line power and to the network. Intel AMT uses a separate management processor that runs
independently on the client machine and can be reached through the wired or wireless network.
1. Click Security > Firewall > Intel® AMT.
2. Complete the elds from the table below and click Save.
Field Description
Ports
When enabled, inbound/outbound rewall rules are added for certain ports to enable Intel AMT
service.
WAN Host
Select ANY to allow all hosts access or select Specify WAN IPs and enter IP addresses of hosts
(separate with a comma) you want to grant access to. Do not use spaces.
WAN Host Addresses
Enter a comma separated list of WAN IP addresses that must be allowed access to the Local Server
in case “Specify WAN IPs” is selected as the WAN Host. Only commas are allowed and there should
be no spaces between the comma and the IP address.
Internal IP Address Enter the LAN IP address.
Reector Toggle to ON to enable Reector. This will send data back to the client on selected ports.
Redirect to Port 16992-
16995
Toggle to ON to use the selected port. Enter the listening port on which the server will listen for
incoming connections.
Redirect to Port 9971
Toggle to ON to use the selected port. Enter the listening port on which the server will listen for
incoming connections.
Save Click it to save your changes.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
