D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 185
Section 8 - Security
Bridge Firewall Rules
Path: Security > Firewall > Firewall Rules > Bridge Firewall Rules
Note: Bridge Firewall Rules is available only in DSR Octeon models.
A rewall is a security mechanism to selectively block or allow certain types of trac in accordance with rules
specied by network administrators. You can use this page to manage the rewall rules that control trac
between interfaces of your Bridged network.
The List of Bridge Firewall Rules table includes all rewall rules for the bridged network and allows several
operations on the rewall rules. By default in Bridge Mode, all access is allowed for Inbound and Outbound
direction between the interfaces of the bridged network. Inbound Rules govern access from DMZ Port to the
LAN Port1 interface. Outbound rules restrict access to trac leaving your LAN Port1 interface. Firewall rules are
applied in the order listed. As a general rule, you should move the strictest rules (those with the most specic
services or addresses) to the top of the list.
To create a new bridge rewall rule:
1. Click Security > Firewall > Firewall Rules > Bridge Firewall Rules tab.
2. The elds displayed on the Bridge Firewall Rules are given below.
Field Description
Status It displays the status of the rule. It can be Enabled (active) or Disabled (congured but not in use).
Direction
It displays the direction of the source of the trac that is controlled by this rewall rule: Inbound or
Outbound.
Service
It displays the service that is controlled by this rewall rule. The name usually indicates the type of
trac the rule covers such as FTP, SSH, telnet, ping, etc. Services that are not present in the list can
be added as a Custom Service.
Action It displays the action to be taken on the enabled rule.
Source Hosts It displays the hosts that originate the trac for this rewall rule.
Destination Hosts It displays the hosts that receive the trac for this rewall rule.
Source MAC It displays the MAC Address of the hosts that originate the trac for this rewall rule.
Destination MAC It displays the MAC Address of the hosts that receive the trac for this rewall rule.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
