D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 167
Section 8 - Security
Path: Security > Authentication > External Auth Server > NT Domain
The NT Domain server allows users and hosts to authenticate themselves via a pre-congured Workgroup
eld. Typically Windows or Samba servers are used to manage the domain of authentication for the centralized
directory of authorized users.
To congure the router to connect to your NT domain server:
1. Click Security > Authentication > External Auth Server > NT Domain tab.
NT Domain Server
2. Complete the NT server information from the table below and click Save. You can congure up to
three servers.
Field Description
Server Check Click it to test the connection(s) to your AD Server(s).
Authentication Server
(1-3)
Enter the IP address of your NT server(s).
Workgroup (1-3) Enter the NT workgroup name(s).
Timeout Set the amount of time in seconds that the router should wait for a response from the AD server.
Retries This determines the number of tries the controller will make to the AD server before giving up.
Administrator Account
Enter the admin account information that will be used when authentication is required for PPTP/L2TP
connection.
Password Enter the admin password.
Save Click Save at the bottom to save and activate your settings.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
