Digi IX10 User Manual

Serial port Configure RealPort mode using the Digi Navigator
IX10 User Guide
229
2. Set the number of data bits used by the device to which you want to connect:
(config)>serial port1 databits bits
(config)>
3. Set the type of parity used by the device to which you want to connect:
(config)>serial port1 parity parity
(config)>
Allowed values are:
n
even
n
odd
n
none
The default is none.
4. Set the stop bits used by the device to which you want to connect:
(config)>serial port1 stopbits bits
(config)>
5. Set the type of flow control used by the device to which you want to connect:
(config)>serial port1 flow value
(config)>
where value is one of:
n
none
n
rts/cts
n
xon/xoff
8. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
9. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Configure RealPort mode using the Digi Navigator
You can configure RealPort mode for the IX10 using the Digi Navigator application. When you install
Digi Navigator on your computer, the RealPort application is automatically installed as well.
With Digi Navigator, you can set all serial ports on the device to RealPort mode, and then also enable
the RealPort service. The COMports on your laptop are also configured. These processes ensure that
RealPort is configured on the device and on your computer.
Operating system
The Digi Navigator can only be installed on a computer with a Windows OS. If you are using Linux,
you can manually install and configure RealPort without Digi Navigator. For the Linux installation
