Digi IX10 hardware reference IX10 LEDs
IX10 User Guide
29
Solid yellow (or orange)
Initializing or starting up.
Flashing yellow (or orange)
In the process of connecting to the
cellular network and to a device on
its ETH port.
Flashing white
ETH port connection established and
in the process of connecting to the
cellular network.
Flashing green
Connected to 2G or 3G1 and is in the
process of connecting to any device
on its ETH port, or nothing is
connected to the port.
Solid green
Connected to 2G or 3G and also has
a device linked to its ETH port.
Flashing blue
Connected to 4G LTE and in the
process of connecting to a device on
its ETH port.
Solid blue
Connected to the 4G LTE and also
has a device link to its ETH port.
Alternating Red/yellow (or orange)
Upgrading firmware.
WARNING! DO NOT POWER OFF DURING FIRMWARE UPGRADE.
1. Or an unknown type of cellular network.
Signal quality indicators
LEDs labeled 1 through 5 Indicate the cellular service quality level.
Signal bars Weighted dBm Signal strength % Quality
-113 to -99 0% to 23% Bad
-98 to -87 24% to 42%
Marginal
-86 to -76 43% to 61% OK
-75 to -64 62% to 80% Good
-63 to -51 81% to 100% Excellent
The weighted dBm measurements are negative numbers, meaning values closer to zero denote a
larger number. For example, a -85 is a better signal than -90.
