Page #117 background imageLoading...
Page #117 background image
Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 101
Fixed Frequency Setpoint Value
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P10.1 124 Fixed frequency FF0 6.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
This value is only active if the setpoint input has been set to
parameter P6.2 = 0
P10.2 105 Fixed frequency FF1 12.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
In the factory setting, this value can be called directly via DI3
(control signal terminal 10)
P10.3 106 Fixed frequency FF2 18.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
In the factory setting, this value can be called directly via DI4
(control signal terminal 14)
P10.4 126 Fixed frequency FF3 24.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
In the factory setting, this value can be called directly by joint
actuation of control signal terminals 10 and 14 (DI3 and DI4)
P10.5 127 Fixed frequency FF4 30.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
For activation, parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15)
This value can then be called up directly via DI3
Note: In the factory setting, DI5 (control signal terminal 15) is
assigned with the error acknowledgement (Reset). Setting
P3.11 = 0 is recommended
P10.6 128 Fixed frequency FF5 36.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
For activation, parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15),
see Note on P10.5)
This value can be called directly by joint actuation of control
signal terminals 10 (DI3) and 15 (DI5)
P10.7 129 Fixed frequency FF6 48.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
For activation, parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15)
see Note on P10.5)
This value can be called directly by joint actuation of control
signal terminals 14 (DI4) and 15 (DI5)
P10.8 130 Fixed frequency FF7 60.00
0.00–P6.4 0.00 Hz up to the maximum frequency value (P6.4)
For activation, parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15),
see Note on P10.5)
This value can be called directly by joint actuation of control
signal terminals 10 (DI3), 14 (DI4) and 15 (DI5)
