Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 103
The run times in the individual program steps must be
greater than the transition times for the subsequent
frequency value. Example as per figure on Page 104
(Example A):
Acceleration time P6.5 = 3.0s
Maximum frequency P6.4 = 60 Hz
FF1: P10.2 = 20 Hz
FF2: P10.3 = 40 Hz
The transition time from FF1 to FF2 is one second.
Parameter P10.13 should therefore be set to a value greater
than one second.
Fixed Frequency Setpoint Value
t
FF
FF x P6.5
P6.4
P10.13
(P10.3–P10.4) x P6.5 (40 Hz–20 Hz) x 3s
1s
P6.4 60 Hz
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P10.11 1438 — Set time for FF0 0
0–1000s 0s = Fixed frequency FF0 deactivated
(sequence control P10.9)
P10.12 1439 — Set time for FF1 0
0–1000s 0s = Fixed frequency FF1 deactivated
(sequence control P10.9)
P10.13 1440 — Set time for FF2 0
0–1000s 0s = Fixed frequency FF2 deactivated
(sequence control P10.9)
P10.14 1441 — Set time for FF3 0
0–1000s 0s = Fixed frequency FF3 deactivated
(sequence control P10.9)
P10.15 1442 — Set time for FF4 0
0–1000s 0s = Fixed frequency FF4 deactivated
(sequence control P10.9)
P10.16 1443 — Set time for FF5 0
0–1000s 0 s = Fixed frequency FF5 deactivated
(sequence control P10.9)
P10.17 1444 — Set time for FF6 0
0–1000s 0s = Fixed frequency FF6 deactivated
(sequence control P10.9)
P10.18 1445 — Set time for FF7 0
0–1000s 0s = Fixed frequency FF7 deactivated
(sequence control P10.9)
