M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 183
Dimensions
Approximate Dimensions in inches (mm)
The graphic is in real size. Use it to mark the cut-out
for the door keypad and the holes for the screws.
Door Keypad Cut-out Dimensions
4.33
(110.0)
3.15 (80.0)
3.54 (90.0)
4.92 (125.0)
0.16
(4.0)
0.98
(25.0)
4.69
(119.0)
6.69
(170.0)
Panel Cut-out 4 pcs ø6

Eaton MMX34AA3D3F0-0 Specifications
