Appendix A
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 177
System Parameters
Note
These parameters are overwritten with the bus-specific parameters when a fieldbus connection (for example, CANopen) is used.
The parameter values described in the manual of the fieldbus interface then apply.
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
Hard- and Software Information
S1.1 833 X ro API SW ID — 125 0
S1.2 834 X ro API SW Version — 125 0
S1.3 835 X ro Power SW ID — 125 0
S1.4 836 X ro Power SW Version — 125 0
S1.5 837 X ro Application ID — 125 0
S1.6 838 X ro Application revision — 125 0
S1.7 839 X ro System load % 125 0
Communication
S2.1
808 X ro Communication status In xx.yyy format
xx = Number of error messages
(0–64)
yyy = number of correct messages
(0–999)
125
S2.2
809 rw Fieldbus protocol 0 = FB disabled
1 = Modbus RTU
125 0
S2.3
810 rw Slave address 1–255 125 1
S2.4
811 rw Baud rate 0 = 300
1 = 600
2 = 1200
3 = 2400
4 = 4800
5 = 9600
6 = 19200
7 = 38400
8 = 57600
125 5
S2.6 813 rw Parity type 0 = None, no, see 2 stop bits
1 = Even, see 1 stop bit
2 = Odd, see 1 stop bit
126 0
S2.7 814 rw Communication timeout 0 = Not used
1 = 1s
2 = 2s
…255 = up to 255s
126 0
S2.8 815 rw Reset communication status 0 = Not used
1 = Resets parameter S2.1
126 0
