Appendix A
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 167
Digital Output
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P5.1 313 rw RO1 Signal
(Relay 1 Output)
0 = Deactivated
1 = READY
2 = RUN
3 = FAULT
4 = Error message (inverted)
5 = ALARM
6 = REV
7 = Output frequency
8 = Motor controller active
9 = Zero frequency
10 = Frequency monitoring 1
11 = Frequency monitoring 2
12 = PID monitoring
13 = Overtemperature signal
14 = Overcurrent control active
15 = Overvoltage control active
16 = PLC Sequence control active
17 = PLC sequence control, single step
completed
18 = PLC sequence control, program cycle
completed
19 = PLC sequence control, pause
20 = Counter, value 1 reached
21 = Counter, value 2 reached
22 = RUN message active
23 = Analog min reference error
24 = LOG function fulfilled
25 = PID controller, actual value
monitoring
26 = External brake actuated
27 = Current monitoring
28 = Fieldbus, remote output
78 2
P5.2 314 rw RO2 signal
(relay output 2)
Like P5.1 79 3
P5.3 312 rw DO Signal
(Digital Output)
Like P5.1 79 1
P5.4 315 rw Frequency monitoring 1 0 = Deactivated
1 = 0.00–P5.5 Hz
2
= P5.5–P6.4 Hz
79 0
P5.5 316 rw Frequency monitoring 1
reference value
0.00–P6.4 Hz 80 0.00
P5.6 346 rw Frequency monitoring 2 0 = Deactivated
1 = 0.00–P5.7
Hz
2 = P5.7–P6.4 Hz
80 0
P5.7 347 rw Frequency monitoring 2
reference value
0.00–P6.4 Hz 80 0.00
P5.8 1457 rw Current monitoring 0.00–P7.2A 81 0.00
