Appendix A
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 173
V/Hz-Characteristic Curve
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P11.1 108 X rw V/Hz characteristic curve 0 = Linear
1 = Squared
2 = Configurable
107 0
P11.2 602 X rw Cut-off frequency 30.00–320.00 Hz 108 60.00
P11.3 603 X rw Output voltage 10.00–200.00% of the motor
rated voltage (P6.5)
108 100.00
P11.4 604 X rw V/Hz characteristic curve,
mean frequency value
0.00–P11.2 Hz 109 60.00
P11.5 605 X rw V/Hz characteristic curve,
mean voltage value
0.00–P11.3% 109 100.00
P11.6 606 X rw Output voltage at 0 Hz 0.00–40.00% 109 0.00
P11.7 109 X rw Torque increase 0 = Deactivated
1 = Enabled
109 0
P11.8 600 X rw Control mode 0 = Frequency control (V/Hz)
1 = Speed control with slip
compensation
109 0
P11.9 601 X rw Carrier frequency 1.5–16.0 kHz 111 6.0
P11.10 522 X rw Sine-wave filter
(constant carrier frequency)
0 = Deactivated
1 = Enabled
111 0
