Appendix A
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 147
Device Series MMX35
Notes
Symbols used in technical data and formulas.
Contact the Eaton Drives Technical Resource Center for technical data.
MMX35AA…NO-O Symbols
Unit 1D7 2D7 3D9 6D1 9D0
Rated operational current (I
e
)I
e
A 1.7 2.7 3.9 6.1 9.0
Overload current for 60s every 600s
at 122°F (50°C)
I
L
A 2.6 4 5.9 9.2 13.5
Starting current for 2s
every 20s at 122°F (50°C)
I
L
A 3.4 5.4 7.8 12.2 18.0
Assigned motor rating 575V HP HP 12357.5
Power side (Primary side)
Number of phases Three-phase
Rated voltage U
LN
V 575V –15%–575V +10%, 60 Hz
Input current I
LN
A 2 3.6 5 7.6 10.4
Maximum leakage current to
ground (PE) without motor
MMX35...N_ I
PE
mA—————
Braking torque
Default I/I
e
%30
Brake chopper with external
braking resistance
Max. 100% rated operational current I
e
with external
braking resistance
Minimum braking resistance R
B
ohms 103 103 103 103 103
Switch-on threshold for the
braking transistor
U
DC
Vdc Programmable P12.6
DC braking I/I
e
% 100, adjustable
Pulse frequency f
PWM
kHz 6 (adjustable 1–16)
Heat dissipation at rated
operational current (I
e
)
P
v
W 190 190
Efficiency h 97.6 97.6
Fan (device-internal,
temperature-controlled)
Installation size FS3 FS3 FS3 FS3 FS3
Weight m Lbs (kg) 2.2 (0.99) 2.2 (0.99) 2.2 (0.99) 2.2 (0.99) 2.2 (0.99)
