Appendix A
150 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Dimensions and Frame Sizes
Note
1 in = 25.4 mm, 1 mm = 0.0394 in
Approximate Dimensions in inches (mm)
Installation
SizePart Number a a1 b b1 b2 c Ø, Ø1 Ø2
MMX12AA1D7_
MMX12AA2D4_
MMX12AA2D8_
2.60
(66)
1.50
(38)
6.30
(160)
5.79
(147)
1.26
(32)
4.02
(102)
0.18
(4.5)
— FS1
MMX32AA1D7_
MMX32AA2D4_
MMX32AA2D8_
MMX34AA1D3_
MMX34AA1D9_
MMX34AA2D4_
MMX11AA1D7_
MMX11AA2D4_
MMX11AA2D8_
MMX11AA3D7_
3.54
(90)
2.46
(62.5)
7.68
(195)
7.17
(182)
1.26
(32)
4.14
(105)
2.17
(5.5)
— FS2
MMX12AA3D7_
MMX12AA4D8_
MMX12AA7D0_
MMX32AA3D7_
MMX32AA4D8_
MMX32AA7D0_
MMX34AA3D3_
MMX34AA4D3_
MMX34AA5D6_
MMX11AA4D8_ 3.94
(100)
2.95
(75)
9.96
(253)
9.53
(242)
1.34
(34)
4.41
(112)
2.17
(5.5)
— FS3
MMX12AA9D6_
MMX32AA011_
MMX34AA7D6_
MMX34AA9D0_
MMX34AA012_
MMX34AA014_
MMX35AA1D7_
MMX35AA2D7_
MMX35AA3D9_
MMX35AA6D1_
MMX35AA9D0_
MMX32AA012_
MMX32AA017_
MMX32AA025_
6.50
(165.0)
5.51
(140.0)
14.57
(370.0)
13.82
(351.0)
13.27
(337.0)
6.61
(168.0)
0.28
(7.0)
0.55
(14.0)
FS4
MMX34AA016_
MMX34AA023_
MMX32AA031_
MMX32AA038_
6.50
(165.0)
5.51
(140.0)
14.57
(414.0)
13.82
(398.0)
15.08
(383.0)
8.07
(205.0)
0.28
(7.0)
0.55
(14.0)
FS5
MMX34AA031_
MMX34AA038_
