M-Max Series Overview
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 9
Technical Data and Specifications
General Rated Operational Data
Notes
Symbols used in technical data and formulas.
122°F (50°C) with lateral clearance of 0.79 in (20 mm) and reduced pulse frequency 4 kHz and altitude 1000m.
Description Symbols
Unit Specification
General
Standards — — EMC: IEC/EN 61800-3,
Safety: IEC/EN61800-5, UL508C
Certifications and manufacturer’s
declarations on conformity
— — EMC: CE, CB, c-Tick
Safety: CE, CB, UL, cUL
Production quality — — RoHS, ISO
®
9001
Climatic proofing p
w
% <95%, average relative humidity, noncondensing (EN50178)
Air quality
Chemical vapors — — IEC721-3-3: Device in operation, Class 3C2
Mechanical particles — — IEC721-3-3: Device in operation, Class 3S2
Ambient temperature
Operation °F (°C) 14° to 122° (–10° to 50°)
Storage °F (°C) –40° to 158° (–40° to 70°)
Installation altitude H ft (m) 0–3281 ft (0–1000m) above sea level, over 3281 ft (1000m) with 1% power
reduction per 328 ft (100m), maximum 6562 ft (2000m), at maximum 122°F
(50°C) ambient temperature
Mounting position — — Vertical ±90 for FS1–FS3
Vertical ±30 for FS4 and FS5
Protection type — — IP20 for FS1–FS3
IP21/NEMA for FS4 and FS5
Busbar tag shroud — — BGV A3 (VBG4, finger- and back-of-hand safe)
Mechanical shock resistance — — IEC 68-2-27
Storage and transport: 15g, 11 ms (in the packaging)
UPS drop test (for applicable UPS weights)
Vibration — — EN 60068-2-6
3–150 Hz, oscillation amplitude 1 mm (peak) at 3–15.8 Hz,
maximum acceleration amplitude 1g at 15.8–150 Hz
Emitted interference with internal EMC filter
(maximum motor cable length)
— — C2: Class A in 1st environment (residential area with commercial utilization)
C3: Class A in 2nd environment (industrial)
MMX…NO-O — — No EMC filter
MMX…FO-O — — C2 in first environment max. 3m motor cable length (FS1–FS3);
15m (FS4 and FS5)
C3 in second environment max. 30m motor cable length (FS1–FS3);
50m (FS4 and FS5)
