168 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Digital Output, continued
Drives Control
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P5.9 1458 rw DO logic
(control signal terminal 13)
0 = N/O
1 = N/C
81 0
P5.10 1331 rw RO1 logic
(control signal terminals 22, 23)
Like P5.9 81 0
P5.11 1332 rw RO2 logic
(control signal terminal 24, 25, 26)
Like P5.9 81 0
P5.12 1459 rw DO, on delay 0.00–320.00s 81 0.00
P5.13 1460 rw DO, off-delay 0.00–320.00s 81 0.00
P5.14 1461 rw RO1, on delay 0.00–320.00s 81 0.00
P5.15 1424 rw RO1, off-delay 0.00–320.00s 81 0.00
P5.16 1425 rw RO2, on delay 0.00–320.00s 81 0.00
P5.17 1426 rw RO2, off-delay 0.00–320.00s 81 0.00
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P6.1 125 rw Primary remote control source 1 = Control signal terminals (I/O)
2 = Operating unit (KEYPAD)
3 = Fieldbus (BUS)
82 1
P6.2 117 rw Primary remote speed reference 0 = Fixed frequency (FF0)
1 = Operating unit (REF)
2 = Fieldbus (BUS)
3 = AI1
4 = AI2
5 = Motor potentiometer
82 3
P6.3 101
X rw Minimum frequency 0.00–P6.4 Hz 83 0.00
P6.4 102
X rw Maximum frequency P6.3–320.00 Hz 83 60.00
P6.5 103 X rw Primary acceleration time (acc1) 0.1–3000s 83 3.0
P6.6 104 X rw Primary deceleration time (dec1) 0.1–3000s 83 3.0
P6.7 505 X rw Start function 0 = Ramp, acceleration
1 = Flying restart circuit
84 0
P6.8 506 X rw Stop function 0 = Free coasting
1 = Ramp, deceleration
84 0
P6.9 500 X rw S ramp 0.00 = Linear
0.1–10.0s (S-shaped)
84 0.0
P6.10 717 X rw REAF, Wait time before
an automatic restart
0.10–10.00s 85 0.50
P6.11 718 X rw REAF, Testing period over three
automatic restarts
0.00–60.00s 85 30.00
P6.12 719 X rw REAF, Start function with
automatic restart
0 = Ramp, acceleration
1 = Flying restart circuit
2 = According to P6.7
85 0
