M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 165
Digital Input
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P3.1 300 rw Start/Stop-Logic 0 = DI1 (FWD), DI2 (REV), REAF
1 = DI1 (FWD) + DI2 = REV
2 = DI1 (Start pulse), DI2 (stop pulse)
3 = DI1 (FWD), DI2 (REV)
72 3
P3.2 403 rw Start signal/Start FWD (1) 0 = Deactivated
1 = Activated via control signal
terminal 8 (DI1)
2 = Activated via control signal
terminal 9 (DI2)
3 = Activated via control signal
terminal 10 (DI3)
4 = Activated via control signal
terminal 14 (DI4)
5 = Activated via control signal
terminal 15 (DI5)
6 = Activated via control signal
terminal 16 (DI6)
72 1
P3.3 404 rw STOP signal/Start REV (1) Like P3.2 72 2
P3.4 412 rw Reverse Like P3.2 72 0
P3.5 405 X rw Ext. fault close (N/O) Like P3.2 72 0
P3.6 406 X rw Ext. fault open (N/C) Like P3.2 73 0
P3.7 414 rw Fault reset Like P3.2 73 5
P3.8 407 rw Run enable Like P3.2 73 0
P3.9 419 rw Fixed frequency,
binary value B0
Like P3.2 73 3
P3.10 420 rw Fixed frequency,
binary value B1
Like P3.2 73 4
P3.11
421 rw Fixed frequency,
binary value B2
Like P3.2 73 0
P3.12 1020 rw PID controller
deactivate
Like P3.2 74 6
P3.13 1400 ——(Not used)
— — —
P3.14 1401 rw External brake,
feedback signal (N/O)
Like P3.2 74 0
P3.15 1402 rw Change acceleration/
deceleration time (acc 2/dec 2)
Like P3.2 74 0
P3.16 1403 rw Stop acceleration/deceleration
time
Like P3.2 74 0
P3.17 1404 rw Block parameter access Like P3.2 74 0
P3.18 1405 rw Motor potentiometer, increase
value
Like P3.2 74 0
P3.19 1406 rw Motor potentiometer,
decrease value
Like P3.2 74 0
