Appendix A
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 163
System Parameters in the Quick Start, continued
Default I/O
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
S2.6 813 rw Parity type 0 = None, no, see 2 stop bits
1 = Even, see 1 stop bit
2 = Odd, see 1 stop bit
126 0
S2.7 814 rw Communication timeout 0 = Not used
1 = 1s
2 = 2s
…255 = up to 255s
126 0
S2.8 815 rw Reset communication status 0 = Not used
1 = Resets parameter S2.1
126 0
S3.1 827 X ro MWh counter MWh 126 —
S3.2 828 X ro Operating days (d) 0–0000 days 126 —
S3.3 829 X ro Operating hours (h) 0–24 h 126 —
S3.4 840 X ro RUN counter, days 0–0000 days 126 —
S3.5 841 X ro RUN counter, hours 0–24 h 126 —
S3.6 842 X ro Fault/alarm counter Trip Counter: 0–0000 126 —
S4.1 830 rw Display contrast 0–15 126 7
S4.2 831 X rw Restore factory defaults 0 = Factory setting or changed value
1 = Restores factory settings for all
parameters
126 0
S4.3 832 rw Password 0000–9999 126
0000
Designation
Terminal Function Parameter
Designation Terminal Function Parameter
DI1 8 Start Fwd P3.1, P3.2 DI6 16 PID Controller Deactivate P3.12
DI2 9 Stop/Start Rev P3.1, P3.3 RO1 (NO) 22/23 Run P5.1, P5.10
DI3 10 Fixed Frequency B0 (12 Hz) P3.9, P10.2 RO2 (NO/NC) 24/25/26 Fault P5.2, P5.11
DI4 14 Fixed Frequency B1 (18 Hz) P3.10. P10.3 DO 13 Ready P5.3, P5.9
DI5 15 Fault Reset P3.7
To Next Page
