M-Max Series Overview
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 11
Power Connection Voltages
Notes
The input voltage of 115V is raised to 230V (output voltage) through an internal voltage double connection.
Rated motor currents for normal four-pole internally and surface-cooled three-phase asynchronous motors
(1500 RPM at 50 Hz, 1800 RPM
at 60 Hz).
Calculated motor output (no standard value).
Part Number
Rated
Current
Overload
Current
(150%) Assigned Motor Rating
Frame Size
I
e
I
e150
P
(230V, 50 Hz)
P
(230V, 60 Hz)
(A) (A) (kW) (A)
(hp) (A)
1 AC 115V, 50/60 Hz
(94–132V ±0%, 45–66 Hz ±0%)
MMX11AA1D7_ 1.7 2.6 0.25 1.4 1/4
1.5
FS2
MMX11AA2D4_ 2.4 3.6 0.37 2 1/2 2.2 FS2
MMX11AA2D8_ 2.8 4.2 0.55 2.7 3/4 2.2 FS2
MMX11AA3D7_ 3.7 5.6 0.75 3.2 1 3.2 FS2
MMX11AA4D8_ 4.8 7.2 1.1 4.6 1-1/2 4.2 FS3
1 AC 230V, 50/60 Hz
(177–264V ±0%, 45–66 Hz ±0%)
MMX12AA1D7_ 1.7 2.6 0.25 1.4 1/4
1.5
FS1
MMX12AA2D4_ 2.4 3.6 0.37 2 1/2 2.2 FS1
MMX12AA2D8_ 2.8 4.2 0.55 2.7 3/4 2.2 FS1
MMX12AA3D7_ 3.7 5.6 0.75 3.2 1 3.2 FS2
MMX12AA4D8_ 4.8 7.2 1.1 4.6 1-1/2 4.2 FS2
MMX12AA7D0_ 7 10.5 1.5 6.3 2 6.8 FS2
MMX12AA9D6_ 9.6 14.4 2.2 8.7 3 9.6 FS3
3 AC 230V, 50/60 Hz
(177–264V ±0%, 45–66 Hz ±0%)
MMX32AA1D7_ 1.7 2.6 0.25 1.4 1/4
1.5
FS1
MMX32AA2D4_ 2.4 3.6 0.37 2 1/2 2.2 FS1
MMX32AA2D8_ 2.8 4.2 0.55 2.7 3/4 2.2 FS1
MMX32AA3D7_ 3.7 5.6 0.75 3.2 1 3.2 FS2
MMX32AA4D8_ 4.8 7.2 1.1 4.6 1-1/2 4.2 FS2
MMX32AA7D0_ 7 10.5 1.5 6.3 2 6.8 FS2
MMX32AA011_ 11 14.4 2.2 8.7 3 9.6 FS3
MMX32AA017_ 17 26.3 4 14.8 5 15.2 FS4
MMX32AA025_ 25 37.5 5.5 19.6 7.5 22 FS4
MMX32AA031_ 31 46.5 7.5 26.4 10 28 FS5
MMX32AA038_ 38 57 11 38 15 28 FS5
