M-Max Series Overview
8 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Examples
MMX11: The input voltage of 115V is raised to 230V (output voltage) through an internal
voltage double connection.
Label Meaning
MMX11AA2D8N0-0 MMX = M-Max
series frequency inverter:
1 = Single-phase power supply
1 = Rated voltage 115V
AA = Type of software version and display unit
2D8 = 2.8A (rated operational current)
N = No integrated interference suppression filter (no filter)
0 = IP20 protection type
–0 = No integrated optional assembly
MMX12AA1D7F0-0 MMX = M-Max
series frequency inverter:
1 = Single-phase power supply
2 = Rated voltage 230V
AA = Type of software version and display unit
1D7 = 1.7A (rated operational current)
F = Integrated radio noise filter
0 = IP20 protection type
–0 = No integrated optional assembly
MMX32AA2D4N0-0 MMX = M-Max
series frequency inverter:
3 = Three-phase input supply voltage
2 = Rated voltage 230V
AA = Type of software version and display unit
2D4 = 2.4A (rated operational current)
N = No integrated interference suppression filter (no filter)
0 = IP20 protection type
–0 = No integrated optional assembly
MMX34AA012F0-0 MMX = M-Max
series frequency inverter:
3 = Three-phase input supply voltage
4 = Rated voltage 400V
AA = Type of software version and display unit
012 = 12A (rated operational current)
F = Integrated radio noise filter
0 = IP20 protection type
–0 = No integrated optional assembly
MMX34AA5D6N0-0 MMX = M-Max
series frequency inverter:
3 = Three-phase input supply voltage
4 = Rated voltage 400V
AA = Type of software version and display unit
5D6 = 5.6A (rated operational current)
N = No integrated interference suppression filter (no filter)
0 = IP20 protection type
–0 = No integrated optional assembly
