Appendix A
166 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Digital Input, continued
Analog Output
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P3.20 1407 rw Motor potentiometer,
set value to zero
Like P3.2 74 0
P3.21 1408 rw PLC program start Like P3.2 74 0
P3.22 1409 rw PLC program pause Like P3.2 75 0
P3.23 1410 rw Counter, input signal Like P3.2 75 0
P3.24 1411 rw Counter, reset Like P3.2 75 0
P3.25 1412 rw Activate secondary remote
control source
Like P3.2 75 0
P3.26 1413 rw Activate secondary remote
speed reference
Like P3.2 75 0
P3.27 1414 rw Activate second parameter set
(2PS)
Like P3.2 75 0
P3.28 1415 rw Fieldbus, remote input Like P3.2 75 0
P3.29 1416 rw Counter reference value 1 0–65535 75 0
P3.30 1417 rw Counter reference value 2 0–65535 75 0
P3.31 1418 rw DI1 logic
(control signal terminal 8)
0 = N/O
1 = N/C
75 0
P3.32 1419 rw DI2 logic
(control signal terminal 9)
Like P3.31 75 0
P3.33 1420 rw DI3 logic
(control signal terminal 10)
Like P3.31 76 0
P3.34 1421 rw DI4 logic
(control signal terminal 14)
Like P3.31 76 0
P3.35 1422 rw DI5 logic
(control signal terminal 15)
Like P3.31 76 0
P3.36 1423 rw DI6 logic
(control signal terminal 16)
Like P3.31 76 0
P3.37 1480 rw Manual mode
Like P3.2 76 0
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN
ro/rw
P4.1 307 rw AO signal (Analog Output) 0 = Deactivated
1 = Output frequency (Hz)
2 = Output current (A)
3 = Torque (%)
4 = PID controller (%)
77 1
P4.2 310 rw AO, minimum value 0 = 0V
1 = 2V (live-zero)
77 1
P4.3 1456 rw AO, gain 0.00–200.00% 77 100.00
P4.4 1477 rw AO, filter time 0.00–10.00s 77 0.0
