Fujitsu PRIMERGY RX2530 M6 User Manual

▶
Push the dummy module into the empty bay until it engages.
Concluding steps
▶
If applicable, "Switching on the server" on page
66.
▶
If applicable, "Installing the front cover with lock" on page 66
.
7.5.7 Replacing a 2.5-inch PCIe SSD module
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: – Installation frame included: tool-less
–
Installation frame excluded: Phillips PH1 / (+) No. 1 screw driver
This procedure is valid, if the PCIe SSD module is controlled by an
onboard controller and the VMD function is enabled in the BIOS. For
more information, see the "Intel Virtual RAID on CPU (Intel VROC) User
Guide".
If the PCIe SSD module is controlled by a RAID controller of the PRAID
EP5xxi/CP5xxi/EP6xxi family
, the PCIe SSD module can be installed
during operation (hot-plug), see "Removing 2.5-inch HDD/SSD
modules" on page
142.
CAUTION
All HDD/SSD modules (drives) must be uniquely identified so that they
can be reinstalled in their original bays later. If this is not done, existing
data can be lost.
Preliminary steps
▶
"Locating the defective server" on page 45.
▶
If applicable, "Removing the front cover with lock" on page 48
.
▶
Identify the physical location of the PCIe SSD module, see "2.5-inch HDD/
SSD configurations" on page 138.
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 151
