9.5 OCP (Open Compute Project) modules
9.5.1 Positions of the OCP modules
Figure 129: Positions of OCP modules at rear side
1 OCP module 1 2 OCP module 2
There are different OCP modules available.
Some OCP modules can be equipped with SFP modules, see
"Handling SFP+ transceiver modules" on page 201.
9.5.2 Installing an OCP module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Expansion cards and backup units
RX2530 M6 Upgrade and Maintenance Manual 211
