17.2.3.4 Indicator on hot-plug PSU
Figure 311: PSU status indicator (AC PSU)
Figure 312: PSU status indicator (DC PSU)
1 PSU status indicator
PSU status indicator (1)
Status Description
flashing green The server is switched off, but mains voltage is present
(standby mode).
green on The server is switched on and operating properly.
Appendix A
422 Upgrade and Maintenance Manual RX2530 M6
