10.2 Basic information
10.2.1 Slots and features
iRMC
S5
external connectors
INDICATE
CSS
TPM
Slot riser card / slot 1(CPU 1)
Battery
SATA
0-3
Slot riser card / slot 2 (CPU 1)
Slot riser card / slot 3 (CPU 2)
Rear Serial
SMB 3
Front
Panel
Micro
SATA
4-7
Internal
USB3.0 /
USB 3
JP3
1
JP2 JP1
1
2
SD
LAN
M.2
SSD1
M.2
SSD2
PWR 4
VROC
CPU 2 DIMM 2J
CPU 2 DIMM 1M
CPU 2 DIMM 1L
CPU 2 DIMM 2L
CPU 2 DIMM 1J
CPU 2 DIMM 2M
CPU 2 DIMM 2K
CPU 2 DIMM 1K
CPU 2
CPU 1
CPU 1 DIMM 2A
CPU 1 DIMM 1D
CPU 1 DIMM 1C
CPU 1 DIMM 2C
CPU 1 DIMM 1A
CPU 1 DIMM 2D
CPU 1 DIMM 2B
CPU 1 DIMM 1B
CPU 2 DIMM 1R
CPU 2 DIMM 2N
CPU 2 DIMM 2P
CPU 2 DIMM 1P
CPU 2 DIMM 2R
CPU 2 DIMM 1N
CPU 2 DIMM 1Q
CPU 2 DIMM 2Q
CPU 1 DIMM 1H
CPU 1 DIMM 2E
CPU 1 DIMM 2F
CPU 1 DIMM 1F
CPU 1 DIMM 2H
CPU 1 DIMM 1E
CPU 1 DIMM 1G
CPU 1 DIMM 2G
PCH
SLIMLINE
5 (CPU2)
SLIMLINE
6 (CPU2)
PWR 3
SMB 2
PWR 2
FAN 8 _SYS
FAN 7 _SYS
FAN 6 _SYS
FAN 5 _SYS
FAN 4 _SYS
FAN 3 _SYS
FAN 2 _SYS
FAN 1 _SYS
SLIMLINE 4
(CPU 2)
SLIMLINE 3
(CPU 2)
LC2
SMB 1
LC1
SLIMLINE 2
(CPU 1)
SLIMLINE 1
(CPU1)
PWR 1
PWR 5
PWR
ODD
Front VGA
SATA
ODD/8
SATA 9
Clear RTC
HDD LED
ROC
OCP 3.0 Slot 1 (CPU1) OCP 3.0 Slot 2 (CPU2)
USB 3.0
Management
VGA
PSU1
PSU2
Figure 182: Slots of the main memory
1 CPU 1 memory slots 2 CPU 2 memory slots
–
Eight channel DDR4 memory architecture (per CPU), 2 DIMMs per channel
–
32 memory DIMM sockets R3 (16 per CPU)
–
Supports RDIMM w/ ECC, 3DS-RDIMM, LRDIMM and Optane PMem
modules
–
Supports DDR4 up to 3200 MT/s
–
Supports Optane PMem capacity of 128 GB, 256 GB and 512 GB
–
Supports Optane PMem up to 3200 MT/s
Main memory
264 Upgrade and Maintenance Manual RX2530 M6
