17.2.2.4 Indicators on hot-plug HDD / SSD / PCIe SSD / EDSFF SSD

modules

Figure 305: Indicators on an HDD / SSD / PCIe SSD module

1 Access indicator 2 Error indicator

Figure 306: Indicators on an EDSFF SSD module

Access indicator (1)

Status Description

off The HDD/SSD is inactive.

green on The HDD/SSD being accessed.

Appendix A

416 Upgrade and Maintenance Manual RX2530 M6
