Remove the front VGA cable from the cable clip (see circle).
▶
Disconnect the front VGA cable from the system board connector "Front
VGA" and remove it.
Installing the dummy cover
Figure 244: Installing the dummy cover
▶
Install the dummy cover.
Concluding steps
▶
"Installing the air duct" on page 74.
▶
"Reassembling" on page
57.
▶
"Connecting the power cord" on page 62.
▶
"Switching on the server" on page 66.
▶
If applicable, "Installing the front cover with lock" on page 66.
14.4.3 Replacing the front VGA
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
– hexagon screw driver 5 mm (for front VGA)
Front panel
334 Upgrade and Maintenance Manual RX2530 M6
