GE Giraffe OmniBed Carestation CS1 Service Manual

Chapter 8: Illustrated Parts
Electrical Enclosure
Service Manual 8-5
8.3 Electrical Enclosure
1. Filter harness......................................................................... 2086378-001
2. Cable twist lock..................................................................... 6600-1197-600
3. Card cage................................................................................ 6600-1347-500
4. Relay board bracket...........................................................6600-1166-500
5. Relay board ............................................................................ 2080429-001
120 V 2 amp fuse.............................................................. 6600-0877-600
230 V 1 amp fuse ............................................................. 6600-0882-600
3.15 amp fuse..................................................................... 2070016-001
6. Repl Kit Elevating base/cnpy trnsfrmr 115/230V. 2078108-001
Elevating base/canopy transformer100V 2078109-001
7. Screw, 5/16-18 x 2 ½......................................................... 6600-1111-400
8. Solid state relay.................................................................... 6600-1003-600
8a. Incubator Solid State relay
8b. heater Solid state relay
9. Screw, M6 x 16 ...................................................................... 6600-0707-421
10. Star washer, M6 internal tooth ................................... 6600-0713-434
11. Flat washer. M6.................................................................. 6600-0712-405
12. Star washer, M6 external tooth.................................. 6600-0713-445
13. Wire shield............................................................................ 6600-1798-500
14. Radiant heater transformer 115/230V................... 2078042-001
Radiant heater transformer100V.............................. 2078103-001
15. Power switch (115V)......................................................... 6600-1014-602
Power switch (230V) ........................................................ 6600-1014-601
16. Line filter ............................................................................... 6600-1006-600
17. Single plug guard
U.S., U.K., Italian, Swiss, Australian (short)............. 6600-1701-500
C.E. cord (long).................................................................... 6600-1857-500
Bumper kit for power cord (40 bumpers) .............. M1135907
18. Accessories plug guard.................................................. 6600-1711-500
Brazilian plug guard ........................................................ M1223636
19. Flat washer, M4.................................................................. 6600-0712-403
20. Lock washer, M4 internal tooth.................................. 6600-0713-432
21. Screw, M4 x 8 ...................................................................... 6600-0706-408
22. Washer, color code........................................................... 6600-0338-400
23. Plug ground......................................................................... 6600-0337-400
24. Power outlet........................................................................ 6600-0583-600
25. Connection panel.............................................................. 2084669-001
26. Circuit breaker.................................................................... 6600-0562-603
27. Nut, M6 .................................................................................. 6600-0340-400
28. Lock washer ........................................................................ 6600-0339-400
29. Electrical enclosure.......................................................... 6600-1346-500
30. Card tension rack (bottom)........................................... 6600-1064-400
31. Control board...................................................................... 2080962-001
32. Card guide (top) ................................................................. 6600-1183-400
33. Hex nut, M5 ......................................................................... 6600-0711-408
34. Lock washer, M5................................................................ 6600-0713-433
35. Card guide (rear)................................................................ 6600-1105-400
