GE Giraffe OmniBed Carestation CS1 Service Manual

Chapter 8: Illustrated Parts
Humidifier
Service Manual 8-31
8.11 Humidifier
1. Flat washer, M3 x 3.2, ID .5 ........................................... 6600-0712-402
2. Split ring lock washer, M3 x 3.1, ID .8....................... 6600-0713-402
3. Screw, M3 x 16 Cheese head Phillips....................... 6600-1255-404
4. Reservoir switch (included in item 21)
5. Button, reservoir switch................................................. 6600-1298-500
6. Top humidifier gasket..................................................... 6600-1293-500
7. Heater mount..................................................................... 6600-1291-500
8. Screw, M3 x 8 Cheese head Phillips,
Teflon coated...................................................................... 6600-1255-401
9. Ramp block.......................................................................... 6600-1777-500
10. Humidifier gasket bottom ............................................ 6600-1294-500
11. Protective insert* .............................................................. 6600-1714-500
12. Reservoir seal ..................................................................... 6600-1495-500
13. Insulating cylinder............................................................ 6600-1182-500
14. Bottom bracket.................................................................. 6600-1181-500
15. Steam outlet........................................................................6600-1296-500
16. Silicone tube........................................................................ 6600-1780-500
17. Heater sheath .................................................................... 6600-1292-500
18. Nut, hex 6 -32..................................................................... 0144-3324-113
19. Split ring lock washer, #6 .............................................. 6600-0345-400
20. Safety thermostat assembly ....................................... 2081692-001
21. Add water thermostat assembly
(includes item 4) ................................................................ 2074884-001
22. Humidifier heater*........................................................... 6600-0224-850
23. Spacer, .125 ID.................................................................... 6600-1779-500
24. Humidifier top bracket................................................... 6600-1295-500
25. Star washer, M3 x 3.2 ID ................................................ 6600-0713-442
26. Screw, M3 x 12 Cheese head Phillips....................... 6600-1255-403
27. Humidifier reservoir......................................................... 6600-0216-850
Reservoir bottom.............................................................. 6600-1493-500
Reservoir lid......................................................................... 6600-1492-500
28. Screw, M3 x 10 skt. hd.................................................... 6600-0707-403
29. Screw, M3 x 10 Cheese hd.
Phillips Teflon coated...................................................... 6600-1255-402
Parts Not Shown
Humidifier assembly
(includes all parts above except reservoir).................... 6600-0245-850
*Always replace item 11 when replacing item 22.
