GE Giraffe OmniBed Carestation CS1 Service Manual

Chapter 8: Illustrated Parts
Harnesses
8-10 Service Manual
8.5 Harnesses
8.5.1 Relay Board Harness Connections
Name Part Number Connector
ISO Transformer Mains 2078042-001 (115V/220V)
2078103-001 (100V)
J49
AC Mains Harness 6600-0731-700 J51
WRM/INC HTR Hardness 6600-0623-700 J54
ISO Adapter HTR Harness 6600-0622-700 J50
Heater Door Switches Harness 6600-0710-700 J31
Hand Hood Control Harness 6600-0744-700 J35
Hood Sensor Harness 2074886-001 J36
Hood Motor Harness 6600-1238-600 J46
E-Base Motor Cable 6600-0753-701 J45
E-Base Foot Control Harness 6600-0715-700 J40
Motor Transformer Harness
(4 wire)
2078108-001 (115V / 220V)
2078109-001 (100V)
J44
INC SSR Harness 6600-0864-700 J39
RAD Warmer SSR Harness 6600-0816-700 (red/black) J38
Connect Air Flow Sensor Harness 6600-0729-700 J33
Air Motor Harness 6600-0711-700 J30
Harness Power Supply AC Input 2093759-001 J48
Power Switch Harness (2-wire) 2074885-001 J47
Motor Transformer Harness
(2-wire)
2078108-011 (115V/220V)
2078109-001 (100V)
J52
Power Switch Harness (4-wire) 2074885-001 J43
DC Supply Harness 6600-0708-700 J41
Water Sensor Harness 6600-0730-700 J32
Humidifier Heater Harness 600-0714-700 J53
DC Power Harness 6600-0701-700 J42
RH Isolation Harness 600-1526-700 J55
Relay Data Harness 6600-0704-700 J37
