Chapter 8: Illustrated Parts
Servo Control Oxygen
8-46 Service Manual
8.15 Servo Control Oxygen
1. Screw, M4 Skt Hd...............................................................6600-0868-402
2. Sensor housing cover .....................................................6600-1876-500
3. Oxygen sensor kit (2 pcs)...............................................2084419-001
4. Sensor gasket.....................................................................6600-1887-500
5. Screw, M3x10L Skt Hd..................................................... 6600-0707-403
6. Split ring washer, M3 ....................................................... 6600-0713-402
7. Flat washer, M3..................................................................6600-0712-402
8. Screw, M2.9x16L, self tap..............................................6600-0709-411
9. Calibration fan with harness*.....................................6600-1510-700
10. Calibration valve assembly
(includes gasket)................................................................6600-1539-700
Calibration valve mounting screws
(2)- M4x12L Fl Hd Skt.......................................................6600-0708-409
11. Male/female shoulder screw.......................................6600-0862-400
12. Push fitting, 90 degree elbow .................................... 6600-0865-400
13. Chassis Vent ........................................................................6600-2017-500
14. Vent cover.............................................................................6600-2018-500
15. Vent screen ..........................................................................6600-2020-500
Vent screens (5)..................................................................6600-0271-850
16. Washer (thin).......................................................................6600-1236-400
17. Panel hex nut......................................................................6600-1275-400
18. M12 Split ring washer .....................................................6600-0713-408
19. Sensor housing ..................................................................6600-1875-500
20. Push fitting, straight ........................................................ 6600-0877-400
21. Screw, M4x6L Button Hd................................................ 6600-0706-407
22. Sensor housing board (also includes the board inside the
sensor housing cover).....................................................2065736-001
23. Sensor plug assembly.....................................................6600-0604-700
Sensor housing assembly (includes all parts above
except item 3).....................................................................6600-1506-700
24. Star washer, int. M4 .........................................................6600-0713-432
Tubing (order by inch)
6 mm black..........................................................................6600-0129-300
from sensors to manifold, 3.9”
from chassis vent to manifold, 3.9”
6 mm white.......................................................................... 6600-0866-400
from cal fan to manifold, 4.7”
from manifold to heatsink vent, 4.7”
* Install fan so flow arrow on side points up into chassis.
@ The date on the sensor is a discard date; the sensor should be removed from service on that date.
