10.1.3 Input and Output Pins
Table 10-1 lists the input and output pins of the free-running timer module.
Table 10-1 Input and Output Pins of Free-Running Timer Module
Channel Name Abbreviation I/O Function
1 Output compare A FTOA
1 Output Output controlled by comparator A of FRT1
Output compare B or FTOB
1 / Output / Output controlled by comparator B of FRT1,
counter clock input FTCI
1 Input or input of external clock source for FRT1
Input capture FTI
1 Input Trigger for capturing current count of FRT1
2 Output compare A FTOA
2 Output Output controlled by comparator A of FRT2
Output compare B or FTOB
2 / Output / Output controlled by comparator B of FRT2,
counter clock input FTCI
2 Input or input of external clock source for FRT2
Input capture FTI
2 Input Trigger for capturing current count of FRT2
3 Output compare A FTOA
3 Output Output controlled by comparator A of FRT3
Output compare B or FTOB
3 / Output / Output controlled by comparator B of FRT3,
counter clock input FTCI
3 Input or input of external clock source for FRT3
Input capture FTI
3 Input Trigger for capturing current count of FRT3
179
