In addition, exposure to any type of intense light can induce photoelectric effects that may lead

to chip malfunction. It is recommended that after programming the chip, you cover the erasing

window with a light-proof label (such as an ultraviolet-shield label).

3. 84-Pin LCC Package Mounting: When mounted on a printed circuit board, the 84-pin LCC

package must be mounted in a socket. The recommended socket is listed in table 17-8.

Table 17-8 Socket for 84-Pin LCC Package

Manufacturer Product Code

Sumitomo 3-M 284-1273-00-1102J

305
