VPP: Programming power (12.5V)

E7 to E0: Data input/output

EA14 to EA0: Address input

OE: Output enable

CE: Chip enable

•

Note: All pins not shown in this figure should be left open.

H8/532

HN27C256 (28 pins)

VPP 1

EA9 24

EO0 11

EO1 12

EO2 13

EO3 15

EO4 16

EO5 17

EO6 18

EO7 19

EA0 10

EA1 9

EA2 8

EA3 7

EA4 6

EA5 5

EA6 4

EA7 3

EA8 25

OE 22

EA10 21

EA11 23

EA12 2

EA13 26

EA14 27

CE 20

VCC 28

Vss 14

EPROM socket

FP-80A CG-84, CP-84

10 21 RES

11 22 NMI

13 25 P30

14 26 P31

15 27 P32

16 28 P33

17 29 P34

18 30 P35

19 31 P36

20 32 P37

21 33 P40

22 34 P41

23 35 P42

24 36 P43

25 37 P44

26 38 P45

27 39 P46

28 40 P47

30 43 P50

31 44 P51

32 45 P52

33 46 P53

34 47 P54

35 48 P55

36 49 P56

37 50 P57

38 51 P60

39 52 P61

60 74 AVCC

516VCC

42 55 VCC

617MD0

718MD1

819MD2

9 20 STBY

51 65 AVss

12 2 Vss

29 24 Vss

71 41 Vss

—42Vss

—64Vss

—83Vss

Figure 17-2 Socket Adapter Pin Arrangements
