Table A-1 (c) Machine Language Coding [Special Format: Branch Instruction]
Operation code
1234
Bcc d:8 BRA (BT) 2 00100000 disp
BRN (BF) 00100001 disp
BHI 00100010 disp
BLS 00100011 disp
BCC (BHS) 00100100 disp
BCS (BLO) 00100101 disp
BNE 00100110 disp
BEQ 00100111 disp
BVC 00101000 disp
BVS 00101001 disp
BPL 00101010 disp
BMI 00101011 disp
BGE 00101100 disp
BLT 00101101 disp
BGT 00101110 disp
BLE 00101111 disp
Bcc d:16 BRA (BT) 3 00110000 disp (H) disp (L)
BRN (BF) 00110001 disp (H) disp (L)
BHI 00110010 disp (H) disp (L)
BLS 00110011 disp (H) disp (L)
BCC (BHS) 00110100 disp (H) disp (L)
BCS (BLO) 00110101 disp (H) disp (L)
BNE 00110110 disp (H) disp (L)
BEQ 00110111 disp (H) disp (L)
BVC 00111000 disp (H) disp (L)
BVS 00111001 disp (H) disp (L)
BPL 00111010 disp (H) disp (L)
BMI 00111011 disp (H) disp (L)
BGE 00111100 disp (H) disp (L)
BLT 00111101 disp (H) disp (L)
BGT 00111110 disp (H) disp (L)
BLE 00111111 disp (H) disp (L)
JMP @Rn 2 00010001 11010rrr
JMP @aa:16 3 00010000 address (H) address (L)
Instruction Byte
351
