2. Basic Bus Cycle (with 1 Wait State) in Expanded Modes

T1 T2 TW T3

A to A

19 0

R/W

DS (Read),

DS (Write),

D to D

(Read)

D to D

(Write)

WAIT

WTS tWTH tWTS tWTH

Figure 20-5 Basic Bus Cycle (with 1 Wait State) in Expanded Modes
