Sensor™ THC 395
Sensor THC Part Program Support
Sensor™ THC offers the ability to configure THC setup parameters through part program codes.
The following parameters are available for use using EIA-274D G59 codes:
Arc Voltage
Pierce / Start Time
Pierce/ Start Height Factor
Cut / Mark Height
Setup is obtained using the following format.
Example: G59 V601 Fvalue
Misc. G Code
Variable Identity
V600 = Plasma 1 Arc Voltage
V601 = Plasma 1 Pierce Time
V602 = Plasma 1 Pierce Height Factor
V603 = Plasma 1 Cut Height
V625 = Plasma 2 Arc Voltage
V626 = Plasma 2 Pierce Time
V627 = Plasma 2 Pierce Height Factor
V628 = Plasma 2 Cut Height
V650 = Marker 1 Arc Voltage
V651 = Marker 1 Start Time
V652 = Marker 1 Start Height Factor
V653 = Marker 1 Mark Height
V675 = Marker 2 Arc Voltage
V676 = Marker 2 Start Time
V677 = Marker 2 Start Height Factor
V678 = Marker 2 Mark Height
Variable Value
The selected value for the variable
Installation and THC Interface
The Sensor ™ THC is supported through various hardware configurations to offer single and multiple
Sensor™ THC operation. Please refer to your exact CNC hardware configuration when installing the
Sensor™ THC.
Warning! Due to potentially high voltages, extreme care should be taken when working inside the
plasma power supply. Work should only be performed by trained service personnel. Please refer to
Power Supply manufacturer instructions.
