6: Instrument programming Series 2600B System SourceMeter® Instrument

Reference Manual

6-10 2600BS-901-01 Rev. B / May 2013

reset()

-- Clear the display.

display.clear()

-- Prompt the user for a voltage value to source.

srcVoltage = display.prompt("+000.00", " V", "Enter source voltage", 5, -20, 20)

-- Prompt the user to enable measurements.

measEnable = display.menu("Measurements?", "ENABLE DISABLE")

if measEnable == "ENABLE" then

-- Prompt the user for the number of measurements.

numMeas = display.prompt("0000", " Rdgs", "Enter the number of readings", 10,

0, 9999)

smua.measure.count = numMeas

smua.nvbuffer1.clear()

end

-- Convert user input to the source level.

smua.source.levelv = tonumber(srcVoltage)

smua.source.output = smua.OUTPUT_ON

if measEnable == "ENABLE" then

-- Inform the user that measurments are in progress

display.setcursor(1, 1)

display.settext("$BPlease wait.$R$NMeasure operation in progress.")

smua.measure.i(smua.nvbuffer1)

display.clear()

-- Inform the user that the Source Measure operation has finished

display.settext("Operation Finished$NSource-Measure Complete")

else

-- Inform the user that the Source operation has finished

display.settext("Operation Finished$NSource Complete")

end

-- Wait 5 seconds then return the the main screen.

delay(5)

display.screen = display.SMUA
