Keithley 2601B Reference Manual

Section
7: TSP command reference Series 2600B System SourceMeter® Instrument
Reference Manual
7-290 2600BS-901-01 Rev. B / May 2013
Details
These attributes are used to read or write to the operation status trigger timer summary registers. Reading a
status register returns a value. The binary equivalent of the returned value indicates which register bits are set.
The least significant bit of the binary number is bit B0, and the most significant bit is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents (on
page E-1) and Enable and transition registers (on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
B0-B9
Not used
Not applicable
B10
status.operation.instrument.trigger_timer.TRIGGER_OVERRUN
status.operation.instrument.trigger_timer.TRGOVR
Set bit indicates one
or more enabled bits
for the operation
status trigger timer
overrun register is set.
Bit B10 decimal value:
1,024
Binary value:
0100 0000 0000
B11-B15
Not used
Not applicable
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
For example, to set bit B10, set operationRegister to 1024.
Example
status.operation.instrument.trigger_timer.enable = 1024
Uses a decimal value to set
the TRGOVR bit of the
operation status trigger timer
summary enable register.
Also see
Operation Status Registers (on page E-9)
status.operation.instrument.trigger_timer.trigger_overrun.* (on page 7-291)
