Keithley 2601B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Appendix B:
Calibration
2600BS-901-01 Rev. B / May 2013 B-3
Recommended verification equipment
The following table summarizes recommended maximum allowable test equipment uncertainty for
verification points. Total test equipment measurement uncertainty should meet or be less than the
listed values at each test point. Generally, test equipment uncertainty should be at least four times
better than corresponding Series 2600B specifications.
Recommended verification equipment
Description Manufacturer/model Accuracy
Digital multimeter
Keithley Instruments
Model 2002
or
Agilent 3458A
DC voltage
1
(2601B/2602B/2604B)
DC voltage
2
(2611B/2612B/2614B/2634B/
2635B/2636B)
DC current
3
90 mV:
0.9 V:
5.4 V:
36 V:
190 mV:
1.8 V:
18 V:
180 V:
90 nA:
0.9 mA:
9 µA:
90 µA:
0.9 mA:
9 mA:
90 mA:
0.9 A:
±8 ppm
±5 ppm
±4 ppm
±6 ppm
±5 ppm
±4 ppm
±6 ppm
±6 ppm
±430 ppm
±45 ppm
±25 ppm
±23 ppm
±20 ppm
±20 ppm
±35 ppm
±110 ppm
0.5 Ω, 250 W, 0.1%
precision resistor
Isotek
RUG-Z-R500-0.1-TK3
Resistance
4
0.5 Ω:
±125 ppm
1 GΩ, 200 V, 1%
standard
Keithley Instruments
Model 2600-STD-RES
Resistance
5
1 GΩ:
±250 ppm
1. Ninety-day specifications show full-range accuracy of recommended model used for specified measurement
point.
2. Id.
3. Id.
4. Resistor used to test Model 2601B/2602B/2604B 3 A range and Model
2611B/2612B/2614B/2634B/2635B/2636B 1.5 A range only should be characterized to uncertainty shown using
resistance function of digital multimeter before use.
5. Standard is a guarded and characterized 1 GΩ resistor that is used to test Model 2634B/2635B/2636B 100 pA to
100 nA current ranges.
