11. Wiring color
(1) Wire color (2) Stripe
• Wire colors are specified in the color codes.
• This symbol of "/" shows color with stripe(s).
W
iring Colors Color code
Black B
Brown BR, Br
Green G
Gray GY, GR
Blue L
Light green LG, Lg
Orange OR, O
Pink P
Purple PU, V, Pu
Red R
Sky blue SB, Sb
White W
Yellow Y
(An example)
W/R:
Red stripe on white color
12. Dispose fluids correctly
• Do not dispose fluids on the ground, down the
drain,
into a stream, pond, or lake. Obey related
environmental protection regulations when you
dispose of oil, fuel, coolant, electrolyte, and other
dangerous materials.
2. GENERAL
GENERAL WORKING PRECAUTIONS
11. Wiring color
