2FB/2FC
1-6-94
Yes
No
End
For copy example 1,
increase the value using
the cursor up key.
For copy example 3,
decrease the value using
the cursor down key.
Press the interrupt key.
Exit maintenance mode.
Press the stop/clear key.
Place an original on the document
processor and make a test copy.
Is the image correct?
(copy example 2)
Setting range (Initial setting)
-32 to +32 (0)
-32 to +32 (0)
Changing the value by 1 moves
the copy image by 0.19 mm.
A larger preset value delays the rear end
cutting timing, and a smaller preset value
advances the rear end cutting timing.
Press the start key.
The new setting is stored.
Enter maintenance mode.
Start
Enter 071 using the numeric
keys and press the start key.
Select the item to be adjusted
on the touch panel.
Touch panel display
ADJUST DATA2: CCD trailing edge timing
ADJUST DATA4: CIS trailing edge timing
(7-2)Adjusting the trailing edge registration
<Procedure>
Figure 1-6-183
Copy
example 1
Original
Copy
example 2
Copy
example 3
To Next Page
