2FB/2FC-3
1-7-4
1-7-6 Upgrading the printer board firmware
Follow the procedure below to upgrade the firmware on the optional printer board.
Firmware upgrading requires the following tools:
Compact Flash (Products manufactured by SANDISK are recommended.)
NOTE
When writing data to a new Compact Flash from a computer, be sure to format it in advance.
Procedure
1. Press the Power key on the operation panel
to off. Make sure that the Power lamp is off
before turning off the main power switch.
And then unplug the power cable from the
wall outlet.
* Turning off the main power switch before
pressing the Power key to off may cause
damage to the equipped hard disk.
2. Insert Compact Flash which has firmware
into the printer board.
3. Insert the power plug and turn the main
power switch on. Upgrading firmware starts.
Figure 1-7-6
4. When upgrading the firmware is completed
correctly, the display in Figure 1-7-6 will be
shown on the operation panel screen.
5. Press the Power key on the operation panel
to off. Make sure that the Power lamp is off
before turning off the main power switch at
the operation panel screen which shown on
Figure 1-7-6. And then unplug the power
cable from the wall outlet.
* Turning off the main power switch before
pressing the Power key to off may cause
damage to the equipped hard disk.
6. Remove Compact Flash from the printer board.
Caution
If pressing the Reset button shown on Fig-
ure 1-7-6, upgrading the firmware will start
again and if turn the main power switch off
before the download is finished, writing for
the program will not finish till the end and
[Checksum error F010] will occur.
1-7-7 Remarks on hard disk unit (HDD) replacement
When replacing the hard disk unit (HDD), the following data is deleted. Set up again if needed.
Storaged image data
Backup data for document management
Backup data for department administration
Backup data for optional network scanner
download end
[∗ ∗ ∗ ∗]
Reset
