2FB/2FC-2.0
2-4-5
Maintenance parts list
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Paper feed pulley PULLEY FEED 2FB06060 7
7
10
48
74
21
Forwarding pulley PULLEY LEADING FEED 2FB06040 7
7
10
46
72
19
Separation pulley LOWER PULLEY FEED 2FB06080 7
10
41
9
MP paper feed pulley PULLEY FEED 2FB06060 9 40
MP forwarding pulley PULLEY LEADING FEED 2FB06040 9 36
MP separation pulley LOWER PULLEY FEED 2FB06080 9 22
Feed pulley UPPER ROLLER REGIST 2FB17020 13 46
Deck conveying roller LOWER ROLLER REGIST 2FB17030 13 15
Main charger unit PARTS,MC-650 302FB93030 2FB93030 17 A05
Main charger wire cleaning pad PARTS,MC CLEANING PAD ASS'Y SP 302FB94050 2FB94050 17 A07
Main charger wire WIRE,MAIN CHARGER 2A068240 17 34
Main charger grid PARTS,GRID ASS'Y SP 302FB94040 2FB94040 17 A08
Slit glass CONTACT GLASS,ADF 2BC12170 16 7
Contact glass CONTACT GLASS 35912010 16 4
Mirror 1 MIRROR A 2FB12140 15 35
Mirror 2 MIRROR B 2FB12180 15 30
Reflector REFLECTOR SCANNER 2FB12130 15 38
Exposure lamp LAMP SCANNER YG 302FB12440 2FB12440 15 40
Original size detection sensor SENSOR ORIGINAL 2C927090 15 58
Drum PARTS,DRUM ASS'Y 302FB93010 2FB93010 17 A02
Potential sensor SENSOR SURFACE POTENTIAL 302FB25090 2FB25090 32 9
Drum heater electrode PARTS,DRUM ELECTRODE ASS'Y 302FB93160 2FB93160 17 A01
Developing unit PARTS,DV-650 302FB93051 2FB93051 18 A01
Transfer belt PARTS TC BELT SP 302FB93220 2FB93220 12 58
Transfer roller ROLLER TRANSFER 2FB16240 12 43
Idle belt roller IDLE BELT ROLLER 2FB16050 12 40
Transfer belt roller ROLLER BELT DRIVE 2FB16060 12 55
Transfer ground roller TC GROUND ROLLER 302FB16370 2FB16370 12 64
Transfer rear guide film REAR FILM TRANSFER 302FB16300 2FB16300 12 68
Transfer rear brush REAR BRUSH TRANSFER CLEANING 302FB16400 2FB16400 12 78
Cleaning unit PARTS,CLEANING ASS'Y 302FB93070 2FB93070 19 A01
Cleaning lamp LAMP CLEANING 2FB27200 17 29
PTC unit PARTS,PTC ASS'Y 302FB93020 2FB93020 17 A03
PTC cleaning pad PARTS,PTC CLEANIG PAD ASS'Y SP 302FB94110 2FB94110 17 13
PTC wire TUNGSTEN WIRE(OX) SP (50M) 74669000 17 15
Lower cleaning roller LOWER ROLLER CLEANING 2FB20450 21 17
Press roller ROLLER PRESSURE 2FB20020 21 12
Press roller separation claw CLAW,PRESS ROLLER 36720493 21 19
Cleaning felt FELT,CLEANING 2A020330 21 63
Fuser thermistor THERMISTOR FUSER 302FB20200 2FB20200 21 32
Fuser heater M HEATER M120 FUSER
HEATER M240 FUSER
2FB20460
2FB20490
21 46
Fuser heater S HEATER S120 FUSER
HEATER S240 FUSER
2FB20470
2FB20500
21 44
