Parameter Name / value range / [default seng] Info
0x2641:005
(P416.05)
HTL input monitoring: Monitoring condions
(HTL inp. monit.: Monit. condion)
From version 04.00
Monitoring condion for HTL input.
If the selected condion is fullled, the response set in 0x2641:006
(P416.06) takes place.
1 Below minimum frequency Input frequency < minimum frequency threshold 0x2641:001 (P416.01)
longer than the deceleraon 0x2641:002 (P416.02).
2 Above maximum frequency Input frequency > maximum frequency threshold 0x2641:003 (P416.03)
longer than the deceleraon 0x2641:004 (P416.04).
3 Below min. or above max. frequency Input frequency < minimum frequency threshold 0x2641:001 (P416.01)
longer than the deceleraon 0x2641:002 (P416.02) OR input frequency >
maximum frequency threshold 0x2641:003 (P416.03) longer than the
deceleraon 0x2641:004 (P416.04).
0x2641:006
(P416.06)
HTL input monitoring: Error response
(HTL inp. monit.: Error response)
From version 04.00
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response to the triggering of the HTL input monitoring.
Associated error code:
28803 | 0x7083 - HTL input fault
0 No response
0x2642:001
(P115.01)
HTL input diagnoscs: Input frequency
(HTL inp. diag.: Input frequency)
Read only: x.x Hz
From version 04.00
Display of the current input value at the HTL input.
0x2642:002
(P115.02)
HTL input diagnoscs: Frequency setpoint
(HTL inp. diag.: Freq. setpoint)
Read only: x.x Hz
From version 04.00
Display of the current input value at the HTL input scaled as frequency
value.
The standard setpoint source for operang mode 0x6060 (P301.00) =
"MS: Velocity mode [-2]" is selected in 0x2860:001 (P201.01).
0x2642:003
(P115.03)
HTL input diagnoscs: PID setpoint
(HTL inp. diag.: PID setpoint)
Read only: x.xx PID unit
From version 04.00
Display of the current input value at the HTL input scaled as process con-
troller value.
The standard setpoint source for the reference value of PID control is
selected in 0x2860:002 (P201.02).
0x2642:004
(P115.04)
HTL input diagnoscs: Torque setpoint
(HTL inp. diag.: Torque setpoint)
Read only: x.x %
From version 04.00
Display of the current input value at the HTL input scaled as torque value
in percent.
100 % ≡ Motor rated torque 0x6076 (P325.00)
The standard setpoint source for operang mode 0x6060 (P301.00) =
"MS: Torque mode [-1]" is selected in 0x2860:003 (P201.03).
0x2630:002
(P410.02)
Sengs for digital inputs: Input funcon
(DI sengs: Input funcon)
Input funcon of the digital terminals DI3 and DI4.
0 Digital input DI3 = digital input
DI4 = digital input
1 HTL encoder (AB) (from version 02.00) DI3 = HTL input for encoder track B
DI4 = HTL input for encoder track A
2 Pulse train (from version 03.00) DI3 = digital input
DI4 = HTL input for pulse train
3 Pulse train/direcon (from version 03.00) DI3 = HTL input for direcon specicaon; HIGH level = counter-clock-
wise (CCW)
DI4 = HTL input for pulse train
Flexible I/O conguraon
Setpoint change-over
HTL input setpoint source
