WIRING DIAGRAMS
Page 2D-2 90-828631R3 MARCH 1999
Electric Start Wiring Diagram
a-PTC Heater
b-Solenoid Coil
c-CDI Unit
d-Trim Down Relay
e-Trim Up Relay
f-Starter
g-Trim Pump
h-20 Amp Fuse
i-Starter Relay
j-Voltage Regulator
k-Cowl Mounted Trim Switch
l-Stator
m-Trigger
n-Oil Pressure Switch
o-Ignition Coil
p-Remote Wiring Plug
q-Spark Plugs
r-Block Temperature Switch
s-Thermo Switch
