BIGFOOT GEAR HOUSING
Page 6B-40
90-828631R3 MARCH 1999
Driveshaft W
ear Sleeve Installation
1.
Install new rubber ring.
2.
Apply a light coat of Loctite 271 on outside diameter of rubber ring.
19152
a
7
Loctite “271” (92-809819)
a-
Ring
3.
Insert sleeve into holder*.
*Component of Wear Sleeve Installation T
ool (91-14310A1).
19169
a
b
a
91-14310A1
a-
Sleeve
b-
Holder
545
547
