CARBURETOR
Page 3B-34
90-828631R3 MARCH 1999
Electrothermal Plunger Installation
1.
Install screws.
2.
Install cover (if so equipped).
28378
a
b
a-
Screw (2)
b-
Cover
Solenoid Coil Installation
1.
Connect wire pull to coil assembly with lock nut.
2.
Install screws and hook spring onto carburetor assembly
.
28378
c
d
b
a
a-
Wire Pull
b-
Lock Nut
c-
Screw (2)
d-
Spring
184
186
