CARBURETOR
Page 3B-2
90-828631R3 MARCH 1999
Specifications
CARBURETOR
Idle rpm (Out Of Gear)
45 hp
40/50 hp
Idle RPM (In Forward Gear)
45 hp
40/50 hp
Wide Open Throttle rpm (WOT)
Range
Main Jet Size
40/45 hp
50 hp
Pilot Jet
Float Height
950
±
25 rpm
825
±
25 rpm
850
±
25 rpm
725
±
25 rpm
5500–6000
#104 for Carburetors 1 and 2
#103 for Carburetors 3 and 4
#1
12
#42
0.39
±
0.02 in. (10.0
±
0.5 mm)
152
154
